XTAR XP4 Panzer Battery Charger

2 Channels 10440/16340/14500/14650/17500/17670/18350/18500/18650/18700 XTAR VP1 Intelli-Battery Charger

Features:

1.Two independent charging channels for 10440/16340/14500/14650/17500/17670/18350/18500/18650/18700 Li-ion battery
2.Algorithm(CC.CV)charging system
3.Optional and adjustable charge current:250mA,500mA,1A
4.VP1 with switchable LCD indicator to display the real-time charging voltage and battery status
5.Activation function for over discharging battery.VP1 can recover the overly dicharging protected batteries
6.Soft start function avoids damage from a large current surge
7.Automatically restart charging when batteries voltage(full charged batteries not taken out from the charger channel)is below 3.9V(batteries may self discharge)
8.Reverse-polarity protection circuit board

Lithium Batteries Charging Parameters
Input Power: 12.0V DC/2.0A
0.25A CC Current: 250±30mA
0.50A CC Current : 500±50mA
1.0A CC Current : 1000±80mA
Cut-Off Voltage: 4.2±0.05V
USB Output Voltage: 5.0±0.3V
USB Output Current: ≤ 1.0A
0.25A/0.5A cut-off current/TC current: ≤ 60mA
1.0A cut-off current/TC current: ≤ 100 mA
Operation Temperature: 0-40°C
Weight: 95g
Size(mm): 118.0 length x 62.0 width x 34.0 height

Ni-MH Batteries Charging Parameter
Input: 12V DC/2.0A
0.25A Pulse charging current: 250±30mA
0.5A Pulse charging current: 500±50mA
1.0A Pulse charging current : 1000±80mA
Cut-off voltage: 1.4±0.05 V
Operation Temperature: 0-40°C

Notice: The above-mentioned parameters tested in Lab are approximate and may vary between flashlight/charger, batteries and environments.
